Creating Features from Existing Data¶

Data Preparation cleans what you have. Feature Engineering creates what you don't.

What You Will Learn¶

Define the architectural difference between Preparation and Engineering
Construct new predictive signals from existing scalar columns
Use Domain Knowledge to encode complex business logic into integers

Prerequisites¶

Completed Topic 1 (Data Preparation)
Understanding of independent variables (Features / X)

Step 1: Mathematical Transformations¶

The simplest feature engineering involves applying basic arithmetic to existing columns to generate a new metric that explains the business problem better.

Using the titanic dataset, an algorithm tracking sibsp (siblings/spouses) and parch (parents/children) separately might miss the broader concept of "Total Family Size". If larger families survive differently than individuals, we must engineer that signal explicitly.

import pandas as pd
import seaborn as sns
import matplotlib.pyplot as plt

df = sns.load_dataset('titanic')

# Feature Engineering: simple arithmetic combination
df['family_size'] = df['sibsp'] + df['parch'] + 1  # +1 for the passenger themselves

print(df[['sibsp', 'parch', 'family_size']].head())

Expected Output

   sibsp  parch  family_size
0      1      0            2
1      1      0            2
2      0      0            1
3      1      0            2
4      0      0            1

Let's test if our engineered feature actually isolates a stronger signal than the raw data:

fig, axes = plt.subplots(1, 2, figsize=(12, 5))

sns.barplot(data=df, x='sibsp', y='survived', ax=axes[0], errorbar=None, color='#6E368A')
axes[0].set_title('Survival by SibSp')

sns.barplot(data=df, x='family_size', y='survived', ax=axes[1], errorbar=None, color='#2D2D2D')
axes[1].set_title('Survival by Engineered Family Size')

plt.tight_layout()
plt.show()

Expected Plot

Engineered Feature Distribution

The rightmost chart now clearly shows a parabolic survival curve: individuals (1) and massive families (6+) died, while medium families (2-4) survived. We captured a complex sociological truth purely with + signs!

Step 2: Binning Continuous Values (Discretization)¶

Algorithms like Decision Trees split numbers arbitrarily. Sometimes, human domain boundaries (e.g. Legal Adult = 18) possess infinitely stronger predictive power than raw continuous distributions.

We can bin the age column dynamically into logical demographic categories using pd.cut().

# Define the arbitrary numeric boundaries and the human labels
bins = [0, 12, 18, 60, 120]
labels = ['Child', 'Teen', 'Adult', 'Senior']

# Execute the cut
df['age_group'] = pd.cut(df['age'], bins=bins, labels=labels)

print(df[['age', 'age_group']].head(6))

Expected Output

    age age_group
0  22.0     Adult
1  38.0     Adult
2  26.0     Adult
3  35.0     Adult
4  35.0     Adult
5   NaN       NaN

Workplace Tip

Do not randomly bin continuous data just because you can! You are mathematically destroying variance (shrinking 100 possible ages into 4 categories). ONLY use pd.cut() when explicit business thresholds exist (e.g. Tax Brackets, Legal Drinking Age) that the algorithm is failing to discover natively.

Step 3: Polynomial Features¶

If a relationship between X and Y is curved rather than a straight line, standard linear regressions will fail completely. You must manually generate exponential features (\(x^2, x^3\)) to allow the line to bend organically.

from sklearn.preprocessing import PolynomialFeatures
import numpy as np

# Synthesize a tiny dataset
X = np.array([[2], [3], [4]])

# Instatiate a Polynomial compiler to generate x^2 components
poly = PolynomialFeatures(degree=2, include_bias=False)
X_poly = poly.fit_transform(X)

print(f"Original X:\n{X}\n")
print(f"Polynomial X (x, x^2):\n{X_poly}")

Expected Output

Original X:
[[2]
 [3]
 [4]]

Polynomial X (x, x^2):
[[ 2.  4.]
 [ 3.  9.]
 [ 4. 16.]]

By passing X_poly into a linear regression model, you mathematically allow a straight line algorithm to trace a parabolic curve!

Summary¶

Mathematical Combinations merge redundant baseline columns into stronger solitary signals.
Discretization (Binning) forces algorithms to respect explicit domain-knowledge thresholds.
Polynomials unlock curved analysis inside strictly linear analytical algorithms.

Next Steps¶

→ Datetime & Text Features — parse complex cyclical timeseries strings into distinct geographic or chronological columns.

Stretch & Challenge

For Advanced Learners¶

Automated Feature Engineering Tooling

If your dataset has 50 columns, manually deriving interactions like col1 * col3 or col4 / col10 requires thousands of human hours and results in 2,500 new columns.

Look into FeatureTools — an open-source library that automates deep feature synthesis relationally.

import featuretools as ft

# FeatureTools automatically multiplies, divides, and groups every column
# against every other column automatically to hunt for hyper-signals.
feature_matrix, feature_defs = ft.dfs(
    dataframes=dataframes,
    relationships=relationships,
    target_dataframe_name="customers"
)

This is highly computationally expensive but routinely wins Kaggle competitions.

KSB Mapping¶

KSB	Description	How This Addresses It
K4.2	Advanced analytics and ML techniques	Feature selection algorithms and dimensionality reduction
K5.2	Data formats and structures	Encoding categorical variables, handling mixed feature types
S2	Data engineering	Creating and transforming features from raw data
S4	Feature selection and ML	Applying feature selection methods and PCA
B1	Inquisitive approach	Exploring creative feature engineering strategies
